Drive Thru系列
Outdoor IP66 Display
Outdoor IP66 Display
This is an outdoor ultra-thin display that breaks the tradition, and the protection level is IP66.
Its brightness can reach up to 5,000 nits, and the AG glass can effectively reduce the reflection from sunlight, so as to achieve the best display effect.
It can be combined with various similar stands to become outdoor kiosk with other appearances.
The delivery time is only 7 days, breaking the trouble of slow delivery of traditional outdoor display.
Its brightness can reach up to 5,000 nits, and the AG glass can effectively reduce the reflection from sunlight, so as to achieve the best display effect.
It can be combined with various similar stands to become outdoor kiosk with other appearances.
The delivery time is only 7 days, breaking the trouble of slow delivery of traditional outdoor display.
Outdoor IP66 Display
Panel
| Size | Resolution | Brightness |
|---|---|---|
| 55"（32"~65" options） | 1920x1080 | 5,000(cd/m²) |
| Display Area | Contrast | Viewing Angle |
| 1209.6 × 680.4 mm (H×V） | 4000:1 | 89°/89°/89°/89° |
| Operating temperature | Display Color | Aspect Ratio |
| -45℃~65℃ (TNI 110℃) | 16.7M | 16:9 |
OS
| System | CPU | RAM |
|---|---|---|
| Android 11 | RK3568 Quad-core 2.0GHz | 2G |
| LAN | Wi-Fi | ROM |
| 10M/100M Ethernet | 802.11b/g/n/ac | 32G |
Touch
| Touch Technology | Touch Points | Touch Life |
|---|---|---|
| PCAP touch | 10 Points | 500 million times |
Degree of protection
| Degree of protection | Explosion-proof grade | |
|---|---|---|
| IP66 | IK10 |
Power
| Input Voltage | Power | |
|---|---|---|
| AC100V~240V(50Hz/60Hz) | 310W |
